Architecture Flow
The whole system contains multiple components that work together to provide a seamless experience. The main components are:
- TEN Agent App: The main application that orchestrates the extensions and manages the data flow between them. It runs as a background process. Depending on the graph configuration, the agent starts the required extensions and handles the data flow between them.
- Front-end UI: A web-based interface to interact with the agent. It allows users to configure the agent, start/stop the agent, and talk to the agent.
- Web Server: A simple Golang web server that serves the HTTP requests. It is responsible for handling the incoming requests and starting/stopping agent processes. It also passes parameter like
graph_nameto determine which graph to use.
The flow of the system is as follows:
